MAX17113 用于LCD TV供电的低成本、多输出电源

MAX17113 用于LCD TV供电的低成本、多输出电源



The MAX17113 multiple-output power-supply controller generates all the supply rails for thin-film transistor (TFT) liquid-crystal display (LCD) panels in TVs and monitors operating from a regulated 12V input. It includes a step-down and a step-up regulator, a positive and a negative charge pump, a Dual Mode™ logic-controlled high-voltage switch control block, and an adjustable-timing power-good output. The MAX17113 can operate from 8V to 16.5V input voltages and is optimized for LCD TV panel and LCD monitor applications running directly from 12V supplies.

The step-up and step-down regulators feature internal power MOSFETs and high-frequency operation allowing the use of small inductors and capacitors, resulting in a compact solution. Both switching regulators use fixed-frequency current-mode control architectures, providing fast load-transient response and easy compensation. A current-limit function for internal switches and output-fault shutdown protect the step-up and step-down power supplies against fault conditions. The MAX17113 provides soft-start functions to limit inrush current during startup. The MAX17113 provides adjustable power-up timing.

The positive and negative charge-pump regulators provide TFT gate driver supply voltages. Both output voltages can be adjusted with external resistive voltage-dividers. The switch control block allows the manipulation of the positive TFT gate driver voltage.

A series p-channel MOSFET is integrated to sequence power to AVDD after the MAX17113 has proceeded through normal startup, and provides True Shutdown™. The MAX17113 is available in a small (5mm x 5mm), low-profile (0.8mm), 40-pin thin QFN package and operates over a -40°C to +85°C temperature range.

关键特性

Optimized for 10.8V to 13.2V Input Supply

8V to 16.5V Input Supply Range

Selectable Frequency (450kHz/600kHz)

Current-Mode Step-Up Regulator

• Built-In 20V, 3.3A, 120mΩ n-Channel MOSFET
• High-Accuracy Output Voltage (1%)
• True Shutdown
• Fast Load-Transient Response
• High Efficiency
• 10ms Internal Soft-Start

Current-Mode Step-Down Regulator

• Built-In 20V, 3A, 120mΩ n-Channel MOSFET
• Fast Load-Transient Response
• Adjustable Output Voltage Down to 1.5
• Skip Mode at Light Load
• High Efficiency
• 3ms Internal Soft-Start

Adjustable Positive and Negative Charge-Pump Regulators

Soft-Start and Timer-Delay Fault Latch for All Outputs

Logic-Controlled High-Voltage Integrated Switches with Adjustable Delay

180mΩ p-Channel FET for AVDD Sequencing

Input Undervoltage Lockout and Thermal- Overload Protection

40-Pin, 5mm x 5mm Thin QFN Package

应用/使用

	LCD监视器面板表
	LCD TV板
